ETS-Lindgren Rentals

ETS-Lindgren

(Showing 12 of 44)

Recognized by clients the world over as the leading supplier of energy management solutions for the industrial and commercial markets. ETS Lindgren has a team of 750 professionals design and manufacture the electromagnetic and acoustic energy components and systems that make many aspects of modern life possible. ETS-Lindgren has cut across industries and market sectors to create a track record of success through such innovations as:

Systems that control unintended electromagnetic energy emissions.
Tools that analyze and measure the performance of wireless devices before they go to market.
Microwave chambers used to test military aircraft before they are put into operation.
Facilities that enable physicians to obtain MRI images and perform surgery in the same room.
Safety monitoring solutions for utility workers who are exposed to electromagnetic fields when they climb telecom and broadcast towers.

ETS-Lindgren Categories

ETS-Lindgren Antennas

Electric Field Probes

GTEM's

Shielded Enclosures/Rooms

Near Field Probe Sets

ETS-Lindgren Test Equipment, Systems & Solutions

ETS-Lindgren 3116C Double-Ridged Waveguide Horn, 10 - 40 GHz

SKU: 3677

Frequency Range: 10 GHz - 40 GHz

Applications: Antenna Pattern Measurements, Emissions

Test Standards: IEC 61000-4-3, ANSI C63.4

Pattern Type: Directional

Maximum Continuous Power: 40 W (10 GHz) to 20 W (40 GHz)

Connectors: Type K (F) (2.92 mm)

VSWR: 2.5:1 Maximum

Typically in Stock

VIEW PRODUCT Cart
ETS-Lindgren 3110C EMC Biconical Antenna

SKU: 284851

Applications: Radiated Emissions Testing

Frequency Range: 30 MHz to 300 MHz

Maximum Continuous Power: 250 mW

VSWR: 2.0:1

Cost New:

Was:

Price Now:

$22.00 - $125.00

Typically In Stock

ORDERING OPTIONS
ETS-Lindgren FP5083 Isotropic Electric Field Probes

SKU: 5972

Dynamic Range: 3 to 300 Volts/meter (V/m)

Frequency Response: 80 MHz - 26 GHz (± 1.5 dB), 26 GHz - 40.0 GHz (± 3.0 dB)

Ranges: 10, 30, 100, 300 V/m full scale

Average Overload: 6 times full scale (each range)

Battery Life: 17 Hrs continuous (full charge)

Cost New:

Was:

Price Now:

$995.00 - $17,500.00

Typically In Stock

ORDERING OPTIONS
ETS Lindgren Series 101 RF Shielded Room

Magnetic: 40 dB @ 1 kHz; 80 dB @ 10 kHz; 120 dB @ 5 MHz to 30 MHz

Electric: 120 dB @ 1 kHz to 30 MHz

Planewave: 120 dB @ 30 MHz to 1 GHz

Microwave: 120 dB @ 1 to 40 GHz

In Stock

VIEW PRODUCT Cart
ETS-Lindgren 5240 Tabletop RF Shielded Test Boxes

Construction: 24 oz Copper Clad Exterior

RF Seal Type: Double Electrical Contact

Ease of Operation: In a Compact, Portable Format

Custom Sizes: Available Upon Request

VIEW PRODUCT Cart
ETS-Lindgren 3183B Broadband Mini-Bicon Antenna

SKU: 114111

Frequency Minimum: 1 GHz

Maximum Continuous Power: 20 W

Impedance (Nominal): 50

VSWR (Average): 2:1

Connector: SMA (Female)

Pattern Type: Directional

Polarization: Linear

Applications: Radiated Emissions Measurements, Military & Aviation EMC Testing

Test Standards: IEC 61000-4-3, CISPR 16-1-4

VIEW PRODUCT Cart
ETS-Lindgren HI-2200 Electric and Magnetic RF Survey Meter

SKU: 30194

Meter Internal Memory: >65,000 data points

User Selectable Units: V/m, μW/cm2, mW/cm2, W/m2 A/m, mA/m

Meter Connector Type: RS-232 I/O serial interface six-pin mini DIN

Test Standards: IEC 61000-4-3

Inquire for Availability

VIEW PRODUCT
Holaday/ETS-Lindgren HI-4455 Electric Field Probe, 200 kHz - 40 GHz

SKU: sku-2086

Cost New:

Was:

Price Now:

$7,500.00
ETS Lindgren 3164-10 Quad-Ridged Horn Antenna

SKU: 2873

Frequency Range: 400 MHz - 10 GHz

Max Power Handling at 400 MHz: 100 Watts

Max Power Handling at 10 GHz: 20 Watts

Connector Types: SMA (f)

Polarization: Dual Linear

VSWR: 1.75:1 Average

Applications: OTA, Antenna Pattern Measurement, OTA Testing

Typically In Stock

VIEW PRODUCT Cart
ETS-Lindgren 3164-04 Diagonal Dual Polarized Horn Antenna

SKU: sku-1907

Frequency Range: 700 MHz - 6 GHz

Applications: Antenna Pattern Measurements, Emissions

Test Standards: IEC 61000-4-3

Gain: 6 - 14 dBi

VIEW PRODUCT Cart
ETS-Lindgren 3301C Active Monopole Antenna

SKU: 21894

Max Frequency: 50 MHz

Min Frequency: 30 Hz

Application/Test Type: Receive-only antenna for Radiated Emissions, Military EMC, Precompliance EMC tesing

Connector: BNC (female)

Impedance: 50 Ohms

Standards Met: FCC Part 15, MIL-STD-461, TEMPEST tests

Antenna Factor: -3 dBm - 13 dB/m

Cost New:

Was:

Price Now:

$345.00 - $3,975.00

Inquire for Availability

ORDERING OPTIONS
ETS-Lindgren 7-TR Antenna Tripod Positioner

SKU: sku-1842

Weight: 2.2 kg

Dimensions: 50 cm x 16 cm x 16 cm

VIEW PRODUCT Cart
