Fischer Custom Communications Categories
Fischer Custom Communications Test Equipment, Systems & Solutions
-
Fischer (FCC) F-65 RF Current Monitoring Probe, 10 kHz - 1 GHz
SKU: 10572
Top Frequency Range: 1 GHzBottom Frequency Range: 10 kHzAC Current Handling (DC-400Hz): 350 AmpsRF Current Handling (CW/Pulse): 3/100 AmpsStyle: Clamp On (Fixed Window)Diameter: 1.25"Transfer Impedance: 1 Ohm$395.00 - $5,475.00In stock -
Fischer FCC F14-1A Current Monitor Probe
SKU: 5199
Frequency Range: 10 Hz to 2 MHzConnector: N-TypeInner Diameter: 67 mmOuter Diameter: 142 mm$400.00 - $4,095.00In Stock -
Fischer FCC F-42 Current Monitor Probe
SKU: 1648
Frequency Range: 1 kHz - 100 MHzAccessory: Hard caseConnector: N-TypeMax RF Current (CW): 50 Amperes$195.00 - $395.00In Stock -
Fischer (FCC) F-72 Current Monitor Probe
Frequency: 100 Hz – 100 MHz3dB Bandwidth: 2MHz - 100MHzConnector: Type-NDC to 60 Hz: 350 amperes400 MHz: 350 amperesRF(CW): 100 amperesPulse: 100 amperesInternal diameter: 67mmExternal diameter: 142mm -
Fischer FCC F-CVP-1 Capacitive Voltage Probe per CISPR 32
SKU: 5642
Applications: Common Mode MeasurementsStandards Met: CISPR 32, EN 55032$195.00 - $995.00Typically in Stock -
Fischer FCC F-33-4 Current Emissions RF Monitor Probe
SKU: 11664
Top Frequency Range: 100 MHzBottom Frequency Range: 1 kHzAC Current Handling (DC-400Hz): 100 AmpsRF Current Handling (CW/Pulse): 2/50 AmpsStyle: Clamp On (Fixed Window)Diameter: 1.25"Transfer Impedance: 1 OhmTest Standards: IEC 61000-4-6Applications: EMC Conducted Emissions Testing$259.00 - $479.00In Stock -
Fischer FCC-BCICF-6-150 Bulk Current Injection Probe Fixtures
SKU: sku-1668
Weight: 2.2kgDimensions: (L x W x H) 432mm x 229mm x 80mmFrequency Range: 150 kHz – 230 MHzInsertion loss: less than 1.6dB -
Fischer FCC-BCICF-1 Bulk Current Injection Probe Fixtures
SKU: sku-1666
Weight: 2.5kgDimensions: (L x W x H) 250mm x 177mm x 175mmFrequency Range: 10 kHz – 400 MHzVSWR: Meets DO-160 standalone limit line -
Fischer F-35A 100 Hz – 108 MHz Current Monitor Probe
SKU: 1819
Aperture: 32 mmConnector type: Type-NDimensions: Internal diameter: 32 mm External diameter: 98 mm Height: 38 mmFrequency range: 100 Hz – 100 MHzGeneral Data: Technical DetailsHigh frequency 3dB cut-off: 108 MHzLow frequency 3dB cut-off: 100 HzMaximum peak current: 100 AmpsOutput resistance: 50 OhmsProbes: Current monitoring$195.00 - $395.00In Stock -
Fischer Custom Communications FCC-LISN-50-100, 50 uH, 100 Amp, Line Impedance Stabilization Network
SKU: 30062
Application/Test Type: Conducted EmissionsCurrent Rating: 100 AmperesFrequency Range: Model Specific, up to 60 HzInductors: 50 µHMains & EUT Connections: Multiple Options AvailableRF Connector: Multiple Options AvailableStandards Met: DO-160F, CISPR 25-1, and MIL-STD-461Voltage Options: 240V or 480 VInquire for Lead Time -
Fischer Custom Communications FCC-801-M3-16A, 3 Line M Series CDN, 150 kHz – 230MHz, 16 Amp
SKU: sku-731
Application/Test Type: 3 Power ConductorsCommon Mode Impedance: Frequency dependent 150 kHz – 26MHz: 150Ω ±20Ω 26MHz – 80MHz: 150Ω +60Ω -45Ω 80MHz –230MHz: 150Ω +60Ω -60ΩCurrent Rating: 16 AmpsFrequency Range: 150 kHz to 230 MHzMains & EUT Connections: Multi-Contact Safety SocketRF Connector: 50 Ω BNC (Female)RF Input Voltage: 30 VoltsStandards Met: IEC / EN 61000-4-6Voltage Division Factor: 10dB+1dB/-3dBVoltage Rating: DC less than 600V, AC less than 250V -
Fischer Custom Communications FCC-801-C1-BNC-50, C Series CDN for RF Coaxial Cables
SKU: sku-729
Application/Test Type: 1 ConductorCommon Mode Impedance: Frequency dependent 150 kHz – 26MHz: 150Ω+20Ω 26MHz – 80MHz: 150Ω+60Ω-45Ω 80MHz –230MHz: 150Ω +60Ω -60ΩCurrent Rating: 1 AmpsFrequency Range: 150 kHz to 230 MHzMains & EUT Connections: BNC 50ΩRF Connector: 50 Ω BNC (Female)RF Input Voltage: 30 VoltsStandards Met: IEC / EN 61000-4-6Voltage Division Factor: 10dB+1dBVoltage Rating: DC less than 600V, AC less than 350V
