Pearson 410 Current Monitor Probe

Pearson 410 Current Monitor Probe

Condition:
Used

No reviews yet Write a Review
Frequency Range:
120 Hz to 20 MHz
Max. Peak Current:
5,000 Amperes
Sensitivity:
0.1 Volt/Ampere +1/-0%
Max. rms Current:
50 Amperes
Output Connector:
BNC (UG-290A/U)
Manufacturer:
Pearson
$1,100.00



SKU:
6154
Availability:

IN STOCK

Getting Started...

Overview

The EMC Shop is an ISO 17025 accredited calibration company with the Pearson 410 Current Monitor Probe in stock available for sale or rental. Repair and refurbishment services available as well. Contact us now for application support.

The Pearson 410 Current Monitor Probe is sealed and suitable for use in high voltage insulating oil or under vacuum. It can be connected to oscilloscopes, spectrum analyzers, power analyzers, digital voltmeters, analog-to-digital convertors, and a variety of other measuring instruments.

Videos

Key Considerations

Manufacturer:
Pearson
Frequency Range:
120 Hz to 20 MHz
Max. Peak Current:
5,000 Amperes
Sensitivity:
0.1 Volt/Ampere +1/-0%
Max. rms Current:
50 Amperes
Output Connector:
BNC (UG-290A/U)
