Isotropic Field Probes & Sensors

Isotropic Field Probes & Sensors Test Equipment, Systems & Solutions

•

  PMM EP-604 300 kHz – 26.5 GHz Broadband Active Electric Field Probe

  SKU: 8554

  Application/Test Type: Monitoring Electric Field Strengths

  Field Strength Range: 0.4 - 800 V/m (0.01 V/m)

  Frequency Range: 300 kHz to 26.5 GHz

  Standards Met: MIL-461 RS103, IEC/EN 61000-4-3, ISO 11452-2, DO-160 Section 20

  Interfaces: Fiber-Optic

  Typically In Stock

  VIEW PRODUCT Cart

•

  Lumiloop LSProbe 2.0 CW and Pulse Field Probe, 9 kHz - 18 GHz

  SKU: 51903

  Application/Test Type: Radiated Immunity, Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms

  Field Strength Range: <1 V/m to 1,000 V/m (5 kV/m under 1 GHz)

  Frequency Range: 9 kHz to 18 GHz

  Resolution: <0.05 V/m

  Test Standards: MIL-STD 461 RS103, DO-160

  Typically In Stock

  VIEW PRODUCT Cart

•

  Amplifier Research FL8018 Isotropic Field Probe, CW and Pulse, 18 GHz

  SKU: 11018

  Frequency Range: 20 MHz - 18 GHz

  Measurement Type: CW, AM & Pulse

  Field Strength Range: 2 – 1000 V/m

  Dynamic Range: >54 dB

  Isotropic Deviation (Measured at Ortho Angle): ±0.5 dB @ 100 MHz

  Applications: Automotive EMC, Commercial EMC, Aviation EMC, Military EMC, Wireless R&D

  Standards Met: MIL-STD 461 RS103, DO-160

  Additional Standards Met: IEC 61000-4-3

  Inquire for Availability

  VIEW PRODUCT Cart

•

  Lumiloop LSProbe 1.2 Laser Powered Field Probe for CW and Pulse Testing

  SKU: 7384

  Application/Test Type: Radiated Immunity

  Field Strength Range: 0.1 V/m to 1,000 V/m (7 to 10 kV/m under 30 MHz)

  Frequency Range: 10 Hz to 8.2 GHz

  Resolution: <0.01 V/m

  Test Standards: MIL-461 RS103, IEC/EN 61000-4-3, ISO 11452-2, DO-160 Section 20

  Typically In Stock

  VIEW PRODUCT Cart

•

  ETS-Lindgren FP5083 Isotropic Electric Field Probes

  SKU: 5972

  Dynamic Range: 3 to 300 Volts/meter (V/m)

  Frequency Response: 80 MHz - 26 GHz (± 1.5 dB), 26 GHz - 40.0 GHz (± 3.0 dB)

  Ranges: 10, 30, 100, 300 V/m full scale

  Average Overload: 6 times full scale (each range)

  Battery Life: 17 Hrs continuous (full charge)

  Cost New:

  Was:

  Price Now:

  $995.00 - $17,500.00

  Typically In Stock

  ORDERING OPTIONS

•

  Holaday/ETS-Lindgren HI-4455 Electric Field Probe, 200 kHz - 40 GHz

  SKU: sku-2086

  Cost New:

  Was:

  Price Now:

  $7,500.00

•

  Wavecontrol WPF3-HP 100 kHz - 3 GHz E-Field Probe

  SKU: 12068

  Field Strength Range: 0.2 - 1,000 V/m

  Application/Test Type: Monitoring electric field strengths

  Videos: Menu Run-Through

  Frequency Range: 100 kHz - 3 GHz

  Typically In Stock

  VIEW PRODUCT Cart

•

  Amplifier Research FL8009 Laser-Powered Electric Field Probe Kit, 20 MHz – 9.3 GHz, CW & Pulse

  SKU: 12060

  Application/Test Type: Radiated Immunity, Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms

  Frequency Range: 20 MHz – 9.3 GHz

  Test Standards: IEC 61000-4-3

  Typically In Stock

  VIEW PRODUCT Cart

•

  ETS-Lindgren HI-6153 Electric Field Probe, 10 MHz - 40 GHz

  SKU: sku-1793

  Application/Test Type: Radiated Immunity

  Field Strength Range: 2 to 800 V/m

  Frequency Range: 10 MHz - 40 GHz

  Standards Met: MIL-STD-461 RS103, DO-160, FORD FMC 1278, SAE J1113/27, ◦ GMW 3091/3097/3103

  Interfaces: Fiber, USB, RS-232

  INQUIRE

  VIEW PRODUCT Cart

•

  Amplifier Research FL7040/Kit 40 GHz E-Field Probe Kit

  SKU: 8937

  Application/Test Type: Radiated Immunity, Monitoring electric field strengths in GTEM's, Anechoic Chambers and other RF rooms

  Test Standards: IEC 61000-4-3, MIL 461 RS103

  Field Strength Range: 2 - 1000 V/m

  Frequency Range: 2 MHz - 40 GHz

  In Stock

  VIEW PRODUCT Cart

•

  Amplifier Research PL7004 800MHz - 3.6GHz Electric Field Pulse Laser Powered Probe

  SKU: 11935

  Amplitude Accuracy: Without correction factors applied: ±1.5 dB @ 1 GHz; With correction factors applied: Typical expanded measurement uncertainty (95% confidence interval), 0.8 dB, 800 MHz–1 GHz; 1.4 dB, 1GHz–3.6 GHz

  Damage Level: 1000 V/m, Continuous Field or Pulsed Field

  Frequency Range: 800MHz - 3.6GHz

  Isotropic Deviation: ±1.0 dB @ 1 GHz. For improved accuracy, this probe should be used with a single axis aligned with the E-field being measured.

  Operating Range: 80–800 V/m

  Pulse Duration: 0.02% to 2%

  Pulse Period: Up to 5 milliseconds between pulses (greater than 200 Hz pulse rate)

  Pulse Width: 1 to 100 Microseconds

  Relative Flatness: ±2.5 dB, 800 MHz-3 GHz; ±3.0 dB, 3.0GHz 3.6GHz

  Temperature Stability: +0.5 dB Over Operating Temperature Range

  Inquire for Availability

  VIEW PRODUCT Cart

•

  Amplifier Research FL7030 5 kHz - 30 MHz Electric Field Laser Powered Probe

  SKU: 11934

  Weight: 62.5 g (2.2 oz)

  Accuracy: ±1.0dB @ 10MHz1 0.8dB, 100kHz–1GHz3,4 1.4dB, 1GHz–6GHz3,4

  Analog Response Time: 20 msec/up to 50 samples per second, at FI7000 USB and GPIB interfaces

  Calibration Data: Accredited Calibration Report (A2LA) supplied with probe

  Damage Level: 1000 V/m continuous field

  Data Returned From Probe: X, Y, Z axes, and Composite

  Dimensions: 5.7 x 5.7 x 5.7 cm (2.25 x 2.25 x 2.25 in) 2.92 cm (1.15 in) DIA spherical housing 3.18 cm (1.25 in) sensor radome per axes

  Fiber Optic Connectors: Two E2000 compact duplex connectors at 1 meter, includes fiber optic verification loop.

  Isotropic Deviation: ± 0.5 dB @ 10 MHz ± 0.5 dB, 5 kHz–30 MHz (typical)

  Linearity: ± 0.5 dB and ± 0.9 V/m

  Operating Range: 1.5–300 V/m

  Operating Temperature: 10˚C to 40˚C (50˚F to 104˚F) @ 5% to 95% RH non-condensing

  Power Requirements: Laser powered from FI7000 interface

  Rise time: Typical Analog 300nS

  Temperature Stability: ± 0.5 dB over operating temperature range

  VIEW PRODUCT Cart
