Standards

Standards Test Equipment

•

  Amplifier Research 40T18G26A TWTA Microwave Amplifier

  SKU: 10716

  Flatness: ± 8 dB maximum

  Frequency Range: 18 GHz – 26.5 GHz

  Gain: 46 dB

  Output: 40 watts

  RF Connector: Type k female

  RENTAL ONLY

  VIEW PRODUCT Cart

•

  Rohde & Schwarz (R&S) NRP-Z55 Thermal Power Sensor

  SKU: sku-714

  RF Field Probe Connector: 2.92 mm connector

  RF Field Probe Frequency Range: DC to 44 GHz

  RF Field Probe Maximum Input Power: 10 W (PK, 1 µs)

  RF Field Probe Measurement Accuracy: Measurement range: –35 dBm to +20 dBm

  Supply Voltage: Operation with R&S®NRP2 base unit or via USB on a Laptop/PC

  Cost New:

  Was:

  Price Now:

  $295.00

  ORDERING OPTIONS

•

  California Instruments OMNI 1-18i Impedance Matching Network

  SKU: 17109

  • Ideal for IEC 61000-3-3 and IEC 61000-3-11 Flicker testing

  • Built in compliance to TR/IEC 60725

  Inquire for Lead Time

  VIEW PRODUCT Cart

•

  Rohde & Schwarz (R&S) RTE1204 Digital Oscilloscope, 2 GHz, 4 channels, 5 Gsample/s, 10/40 Msample

  SKU: 30048

  Bandwidth: 2 GHz

  Realtime sampling rate: max. 5 Gsample/s on each channel

  Trigger types: edge, glitch, width, runt, window, timeout, interval, slew rate, data2clock, pattern, state, serial pattern, TV/video, serial bus trigger (optional)

  Channels: 4

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Cost New:

  Was:

  Price Now:

  $950.00

  Inquire for Availability

  ORDERING OPTIONS

•

  Rent RF Conducted Immunity Test System per IEC 61000-4-6

  SKU: 0699

  Test Capabilities: RF Conducted Immunity

  Standards Met: IEC/EN 61000-4-6

  Applications: CE Marking, Medical Devices, Industrial Machinery, Electronics & IT

  CDN Test Levels (w/ built-in amplifier): 100Vrms

  BCI Test Levels (w/ built-in amplifier): 30V

  IN STOCK

  VIEW PRODUCT Cart

•

  GRC Series Ground Cable w/ 470k Ohm Resistors for ESD Voltage Bleeding

  SKU: 30180

  Total Resistance: 1 MOhm (± 1%)

  Connector Type: 1/4" Spade

  Cable Voltae Withstand: 40kV (150 degrees C)

  Length: 1.5, 2 and 3 Meters

  Resistance: HV Precision Resistors (1% tolerance)

  Cost New:

  Was:

  Price Now:

  $279.00 - $499.00

  In Stock

  ORDERING OPTIONS

•

  GTEM 250 Electromagnetic Transverse Waveguide Cell

  SKU: sku-677

  Max EUT Size: 8" x 8" x 6"

  Frequency Range: DC - 20 GHz

  Max Input Power (CW): 1000 Watts

  Max Input Power (Pulse): 2,500 Watts

  Dimensions (Footprint): 50" x 25" x 17"

  IN STOCK

  VIEW PRODUCT Cart

•

  AH Systems SAS-540 Biconical Antenna, 20 MHz to 330 MHz, up to 2 V/m

  SKU: sku-674

  Weight: 3.8 lb.'s (1.72 kg)

  Antennas: Biconical Antennas

  Application/Test Type: Radiated emissions and immunity

  Connector: N-type (female)

  Dimensions: Height: 29 in. (73.7 cm) Width: 52.5 in. (133.4 cm)

  VIEW PRODUCT Cart

•

  Tektronix DPO4054 Digital Oscilloscope, 4 Channels, 500 MHz

  SKU: 30047

  Bandwidth: 500 MHz

  Channels: 4

  Maximum Waveform Capture Rate: 3,700 wfms/s

  Sample Rates: Up to 5 GS/s on All Channels

  Applications: How to Capture an Electrical Transient Using an Oscilloscope, EMC Precompliance Testing

  Inquire for Availability

  VIEW PRODUCT Cart

•

  Com-Power LI-3P-216 LISN, 9 kHz to 30 MHz, 50/250 uH, 500 VAC

  SKU: 11665

  Weight: 27.5 lbs.

  Application/Test Type: Power Line Conducted Emissions Tests

  Current Rating: 16 Amperes

  Dimensions: 19.3” x 13.9” x 2.3"

  Frequency Range: 9 kHz to 30 MHz

  Cost New:

  Was:

  Price Now:

  $5,795.00

  SHIPS IN 3-5 DAYS

  ORDERING OPTIONS

•

  ESD Guns IF Insulating Foil for ESD Compliance Testing

  SKU: 11647

  Cost New:

  Was:

  Price Now:

  $197.00

•

  3ctest TCXS111 Power Frequency Magnetic Field Coil for IEC61000-4-8, -9, -10

  SKU: sku-602

  # of turns: single

  Dimensions: 1000*1000mm - Length*Width

  Magnetic Field Strength: 1A/m ~ 400A/m

  Standards Met: IEC 61000-4-8, IEC 61000-4-9, IEC 61000-4-10

  Generic Standards: IEC 61000-6-1, IEC 61000-6-2

  4-6 Weeks

  VIEW PRODUCT Cart
